A-PEX Rack Plate Loaded
A-PEX Rack Plate Loaded
AL-APEX-PL
All in one machine – Rack, cable system, Smith Machine
Use your own plates – up to 150kg per side, no stack needed
Any angle adjustable – thanks to Pivot Arms on the cables
Fully expandable – A-Line accessories fit perfectly
Couldn't load pickup availability
Usually ready in 24 hours
A-PEX Rack Plate Loaded
-
cross equip Schweiz
Pickup available, usually ready in 24 hours
Schanzstrasse 1
8330 Pfäffikon ZH
Switzerland+412160746
Description
The flagship for those with their own weights
The A-PEX Rack Plate Loaded offers the same training variety as the A-PEX with weight stack – but you use your own weight plates. Power Rack, cable system and integrated Smith Machine in under 5m². Home gym, personal trainer, physio practice, athletic center or hotel gym – the A-PEX fits anywhere. Squats, bench press, pull-ups, lat pulldowns, guided Smith exercises – all on one machine. The Pivot Arms on the cable system adjust to any angle. With the Connector Plate you combine both sides for seriously heavy sessions – up to 300kg resistance. Perfect if you already have bumper plates and want to use them.Lighter, quieter, more flexible
At 170kg, the Plate Loaded is significantly lighter than the stack version – easier to transport and set up. Without a weight stack there's no clanking – ideal for apartments or early morning training. You decide how much resistance you need: just add more plates, up to 150kg per side. The front uprights are stainless steel – stay scratch-free for years. As part of the A-Line series all accessories fit: Dip Attachment, Landmine, Safety Arms – can be added anytime.
A-Line – Dein Gym, dein System.
Dieses Produkt ist Teil der A-Line – gebaut, um mit dir zu wachsen. Starte klein, erweitere jederzeit. Ein System, alle Möglichkeiten.
Technical Specifications
| Length | 160 cm |
|---|---|
| Width | 187 cm |
| Height | 225 cm |
| Packaging size | 230 x 83 x 55 cm |
| Weight | 170 kg |
| Tube profile | 75 x 75 mm |
| Steel thickness | 3 mm |
| Material front | Stainless steel (Uprights) |
| Material rear | Steel, powder-coated black |
| Cable system | Plate Loaded, 2 sides |
| Smith Machine | Integrated, guided bar |
| Max. cable load | approx. 150 kg per side |
| Weight plate diameter | 50 mm Olympic Standard |
| Hole spacing | 5 cm |
| Hole diameter | 17 mm |
| Compatibility | A-Line series |
A-PEX Plate Loaded vs. Weight Stack
| Property | A-PEX Plate Loaded | A-PEX Weight Stack |
|---|---|---|
| Weight system | Own plates (up to 150kg/side) | Integrated 2x100kg stack |
| Max. weight with Connector Plate | 300 kg | 200 kg |
| Rack weight | 170 kg (lighter) | 350 kg |
| Noise level | Quiet (no stack clanking) | Stack noise |
| Weight changes | Load/unload plates | Instant via pin |
| Ideal for | Those who already have plates | Complete solution |
Already have bumper plates? The Plate Loaded saves money and offers even more maximum resistance. Want everything included? Then the Weight Stack is the right choice.
Frequently Asked Questions
How much space do I need for the A-PEX Rack?
What's all integrated?
Which weight plates fit?
Can I combine both cable sides?
Is the plate-loaded system quieter?
How much weight can I load maximum?
Who is the A-PEX Plate Loaded designed for?
Customer reviews
We developed the Plate Loaded for everyone who already has bumper plates. Same quality, same functions – rack, cable system, Smith Machine – but you use your own weights. Lighter, quieter, and with the Connector Plate even more maximum resistance than the stack version.
